SS316L SS304 Pneumatic Control Valve Trunnion Ball Actuator Double Acting Spring Return

Name: SS316L SS304 Pneumatic Control Valve Trunnion Ball Actuator Double Acting Spring Return
Brand: TOBO
Price: 51 USD

China SS316L SS304 Pneumatic Control Valve Trunnion Ball Actuator Double Acting Spring Return wholesale

Brand Name : TOBO

Model Number : /

Certification : ISO

Place of Origin : CHINA

MOQ : 1pcs

Price : 51USD

Payment Terms : D/A, D/P, T/T, Western Union, MoneyGram, Western Union

Supply Ability : 3000PCS/WEEK

Delivery Time : 10-15DAYS

Packaging Details : Usually bubble pack for each valve within carton box or plywood case, or special packaging upon customer requirements.

Port Size : 1/2"-12"

Selling Units : Single item

Single package size : 50X35X35 cm

Quantity(Pieces) : 1 - 20

Est. Time(days) : 15

Material : SS304 or SS316L

Design standard : API 608/API6D

Packing Details : Usually bubble pack for each valve within carton box or plywood case

Valve body : CF8 or CF8M

Power : Pneumatic

Contact Now

Pneumatic Ball Valves Trunnion Ball Actuator Double Acting Spring Return New Model

Product Description and Materials of Pneumatic ball valve

Technical Specifications
Nominal diameter	2”-48”(DN50-DN1200)
Connection Type	Raised face flange(RF)/Ring joint(RTJ)/Butt weld(BW)
Design standard	API 608/API6D
Body material	Carbon steel WCB/LCB/A105/LF2,Stainless steel CF8/CF8M/CF3/CF3M
Ball material	Stainless steel 304/316/304L/316L
Seat material	PTFE/PPL/NYLON/PEEK/Metal to Metal
Working temperature	Up to 120°C for PTFE
	Up to 250°C for PPL/PEEK
	Up to 80°C for NYLON
Flange end	EN1092-1 PN10/16,ASME B16.5 Cl150-2500lbs
Face to face	ASME B 16.10
ISO mounting pad	ISO5211
Inspection standard	API598/EN12266/ISO5208
Type of operation	Pneumatic actuator double acting/Spring return

1. 3-Piece Full Port Ball Valve

2. Valve body and trim are made in stainless steel and the sealing material is PTFE

3. The ball valve has a pressure rating to 1000 PSI and a temperature rating from 14°F to 356°F

4. This valve comes with a double acting pneumatic actuator with a mounting pad ISO 5211

5. Good corrosion resistance and long life

6. Threaded End Connections

7.Applicable medium: Air, Gas, Liquid, Water, Steam

8.Size range 1/2" to 4"

Features

・Full port design ・Balanced encapsulated construction minimizes cold flow ・Precision stainless steel balls reduce torque and friction losses while extending sat life ・Lockable handle can prevent accidental actuation ・Integral ISO 5211 mounting pad ・Sizes are available from 1/2inch/DN15 to 4inch/VDN100 ・Connection: Welding, Clamp, Male or others upon request.

Option

・ Automatic operation : pneumatic stainless steel actuator (vertical type), pneumatic aluminum actuator (horizontal type), and electric actuator NC operated: normally closed (fail closed)--airto open, spring to close NO operated: normally open (fail open)™air to close, spring to open AA operated: double acting—air to open, air to close ・Valve intelligent control: position sensor, C-top controller, C-top controller (AS-I)

Product Description

Product Name:	Manual 3-Piece Ball Valve With Mounting Pad
Material:	SS304 Or SS316L
Valve Stem Design :	Anti-flying
Standard:	3A, SMS, DIN, RS/RJT, ISO/IDF,ASME/BPE...
Size:	1/2" -4" , DN15-DN100
Operating Type:	Manual,Pneumatic
Valve body:	CF8 or CF8M
Seal Material:	Silicon, EPDM, PTFE
Standard:	SMS, DIN, RJT, IDF
Packing Details:	Usually bubble pack for each valve within carton box or plywood case, or special packaging upon customer requirements.
